Description
Max.shear thickness(mm) | Max.shear width(mm) | Shear angle(°) | Number of stroke(min) | Back gauge range(mm) | Motor power(kw) | Net weight(kg) | Dimensions(mm) | |
QC11Y-4×2000 | 4 | 2000 | 1°30´ | 22 | 20-480 | 4 | 3200 | 2630×2030×1600 |
QC11Y-4×2500 | 4 | 2500 | 1°30´ | 20 | 20-480 | 4 | 3800 | 3130×2030×1600 |
QC11Y-4×3200 | 4 | 3200 | 1°30´ | 20 | 20-600 | 5.5 | 5600 | 3840×2175×1600 |
QC11Y-4×4000 | 4 | 4000 | 1°30´ | 18 | 20-600 | 5.5 | 7000 | 4640×2320×1600 |
QC11Y-6×2500 | 6 | 2500 | 1°30´ | 18 | 20-600 | 7.5 | 5200 | 3130×2320×1600 |
QC11Y-6×3200 | 6 | 3200 | 1°30´ | 16 | 20-600 | 7.5 | 6500 | 3840×2320×1620 |
QC11Y-6×4000 | 6 | 4000 | 1°30´ | 14 | 20-600 | 7.5 | 8500 | 4630×2495×1700 |
QC11Y-6×6000 | 6 | 6000 | 1°30´ | 6 | 20-900 | 11 | 16800 | 6645×2530×2250 |
QC11Y-8×2500 | 8 | 2500 | 1°30´ | 14 | 20-600 | 11 | 6200 | 3140×2345×1620 |
QC11Y-8×3200 | 8 | 3200 | 1°30´ | 12 | 20-600 | 11 | 7300 | 3850×2345×1620 |
QC11Y-8×4000 | 8 | 4000 | 1°30´ | 10 | 20-600 | 11 | 9600 | 4630×2495×1700 |
QC11Y-8×6000 | 8 | 6000 | 1°30´ | 6 | 20-900 | 15 | 17600 | 6650×2845×1700 |
QC11Y-12×2500 | 12 | 2500 | 1°30´ | 12 | 20-900 | 18.5 | 9600 | 3235×3050×2100 |
QC11Y-12×3200 | 12 | 3200 | 1°30´ | 10 | 20-900 | 18.5 | 12000 | 3945×3050×2100 |
QC11Y-12×4000 | 12 | 4000 | 1°30´ | 8 | 20-900 | 18.5 | 14500 | 4745×3210×2200 |
QC11Y-12×6000 | 12 | 6000 | 1°30´ | 5 | 20-900 | 22 | 29500 | 6745×3430×2300 |
QC11Y-16×2500 | 16 | 2500 | 2° | 12 | 20-900 | 22 | 11600 | 3410×3230×2230 |
QC11Y-16×3200 | 16 | 3200 | 2° | 10 | 20-900 | 22 | 14000 | 4120×3230×2230 |
QC11Y-16×4000 | 16 | 4000 | 2° | 8 | 20-900 | 22 | 18000 | 4920×3330×2700 |
QC11Y-16×6000 | 16 | 6000 | 2° | 6 | 20-900 | 37 | 43000 | 7100×3530×2700 |
QC11Y-20×2500 | 20 | 2500 | 2°30´ | 10 | 20-900 | 37 | 17500 | 3420×3330×2700 |
QC11Y-20×3200 | 20 | 3200 | 2°30´ | 8 | 20-900 | 37 | 25500 | 4180×3330×2700 |
QC11Y-20×4000 | 20 | 4000 | 2°30´ | 6 | 20-900 | 37 | 29000 | 4980×3480×2830 |
QC11Y-20×6000 | 20 | 6000 | 2°30´ | 4 | 20-900 | 75 | 56500 | 7180×3580×2830 |
QC11Y-25×2500 | 25 | 2500 | 2°30´ | 8 | 20-900 | 45 | 24000 | 3480×3430×2700 |
QC11Y-25×3200 | 25 | 3200 | 2°30´ | 7 | 20-900 | 45 | 32000 | 4180×3430×2700 |
QC11Y-25×4000 | 25 | 4000 | 2°30´ | 6 | 20-900 | 45 | 39500 | 4980×3580×2800 |
QC11Y-32×2500 | 32 | 2500 | 3° | 6 | 20-900 | 55 | 33000 | 3760×4405×3150 |
QC11Y-32×3200 | 32 | 3200 | 3° | 6 | 20-900 | 55 | 40500 | 4590×4405×3150 |
Product Parameters
